Android 音频开发:PCM转WAV格式 / PCM 文件转 WAV 文件

本文档旨在介绍将未压缩的 PCM 音频文件转为WAV文件,只需要在 PCM 文件的起始位置加上44个字节的 WAV 头信息即可。

所有 WAV 文件都有一个文件头,是 WAV 文件的开始。用于提供关于文件类型、采样率、样本大小和文件位大小的规格,以及其总长度。

WAV 格式介绍:

WAV 文件的头部长度为 44 字节,格式如下:

位置

样本值

描述

1 - 4

"RIFF"

标记文件为 riff 文件。字符每个 1 字节长。

5 - 8

文件大小(整数)

整个文件的大小 - 8 字节,以字节(32 位整数)为单位。通常,你会在创建后填充这个。

9 -12

"WAVE"

文件类型头部。对于我们的目的,它总是等于 "WAVE"。

13-16

"fmt "

格式块标记。包括尾随的 null

17-20

16

fmt Chunk数据的长度

21-22

1

格式类型(1 是 PCM)- 2 字节整数

23-24

2

通道数 - 2 字节整数

25-28

44100

采样率 - 32 字节整数。常见的值是 44100(CD),48000(DAT)。采样率 = 每秒样本数,或赫兹。

29-32

176400

每次采样的大小:(位宽 * 通道数) / 8.

33-34

4

(位宽 * 通道数) / 8.1 - 8 位单声道2 - 8 位立体声/16 位单声道4 - 16 位立体声

35-36

16

位宽

37-40

"data"

"data" 块头。标记数据部分的开始。

41-44

文件大小(数据)

数据部分的大小。

PCM转WAV格式的 Kotlin 实现

package cn.itmob.audio.process

object AudioUtil {
    //采用频率: 16K
    internal val AUDIO_SAMPLE_RATE = 16000
    //声道: 单声道
    internal val AUDIO_CHANNEL: Int = AudioFormat.CHANNEL_IN_MONO
    //编码: PCM
    internal val AUDIO_ENCODING: Int = AudioFormat.ENCODING_PCM_16BIT
    //位宽/采样位数
    internal val BIT_PER_SAMPLE: Int = 16
    //声道数
    internal var CHANNEL_COUNT = 1

    /**
     * Convert pcm file to wav file
     *
     * @param inFilename  pcm file
     * @param outFilename wav file
     */
    fun pcmToWav(context: Context, fcmPath: String, wavPath: String): String {
        val wavOutputFile = File(wavPath)
        val totalAudioLen: Long

        val bufferSize = AudioRecord.getMinBufferSize(AUDIO_SAMPLE_RATE, AUDIO_CHANNEL, AUDIO_ENCODING);
        val data = ByteArray(bufferSize)
        try {
            val input = FileInputStream(File(fcmPath))
            val output = FileOutputStream(wavOutputFile)
            totalAudioLen = input.channel.size()

            writeWaveFileHeader(output, totalAudioLen)

            while (input.read(data) != -1) {
                output.write(data)
            }
            input.close()
            output.close()
        } catch (e: IOException) {
            e.printStackTrace()
        }
        return wavOutputFile.absolutePath
    }

    /**
     * Add WAV header
     */
    private fun writeWaveFileHeader(
        out: FileOutputStream,
        totalAudioLen: Long,
    ) {
        val header = getWavFileHeader(totalAudioLen)
        out.write(header, 0, 44)
    }

    private fun getWavFileHeader(totalAudioLen: Long): ByteArray {
        val totalDataLen = totalAudioLen + 36   //44-8(RIFF+dadasize(4个字节))
        val longSampleRate = AUDIO_SAMPLE_RATE.toLong()
        val channels = CHANNEL_COUNT
        val byteRate = (BIT_PER_SAMPLE * AUDIO_SAMPLE_RATE * channels / 8).toLong()

        val header = ByteArray(44)
        header[0] = 'R'.code.toByte() // RIFF/WAVE header
        header[1] = 'I'.code.toByte()
        header[2] = 'F'.code.toByte()
        header[3] = 'F'.code.toByte()
        header[4] = (totalDataLen and 0xff).toByte()
        header[5] = (totalDataLen shr 8 and 0xff).toByte()
        header[6] = (totalDataLen shr 16 and 0xff).toByte()
        header[7] = (totalDataLen shr 24 and 0xff).toByte()
        header[8] = 'W'.code.toByte() //WAVE
        header[9] = 'A'.code.toByte()
        header[10] = 'V'.code.toByte()
        header[11] = 'E'.code.toByte()
        header[12] = 'f'.code.toByte() // 'fmt ' chunk
        header[13] = 'm'.code.toByte()
        header[14] = 't'.code.toByte()
        header[15] = ' '.code.toByte()
        header[16] = 16 // 4 bytes: size of 'fmt ' chunk
        header[17] = 0
        header[18] = 0
        header[19] = 0
        header[20] = 1 // format = 1
        header[21] = 0
        header[22] = channels.toByte()
        header[23] = 0
        header[24] = (longSampleRate and 0xffL).toByte()
        header[25] = (longSampleRate shr 8 and 0xffL).toByte()
        header[26] = (longSampleRate shr 16 and 0xffL).toByte()
        header[27] = (longSampleRate shr 24 and 0xffL).toByte()
        header[28] = (byteRate and 0xffL).toByte()
        header[29] = (byteRate shr 8 and 0xffL).toByte()
        header[30] = (byteRate shr 16 and 0xffL).toByte()
        header[31] = (byteRate shr 24 and 0xffL).toByte()
        header[32] = (channels * BIT_PER_SAMPLE / 8).toByte()
        header[33] = 0
        header[34] = BIT_PER_SAMPLE // bits per sample
        header[35] = 0
        header[36] = 'd'.code.toByte() //data
        header[37] = 'a'.code.toByte()
        header[38] = 't'.code.toByte()
        header[39] = 'a'.code.toByte()
        header[40] = (totalAudioLen and 0xffL).toByte()
        header[41] = (totalAudioLen shr 8 and 0xffL).toByte()
        header[42] = (totalAudioLen shr 16 and 0xffL).toByte()
        header[43] = (totalAudioLen shr 24 and 0xffL).toByte()
        return header
    }
